Truck ECM Course Overview
A truck ECM (Engine Control Module) repair course is designed to provide students with the essential knowledge and skills needed to diagnose and repair problems related to truck ECMs. The course covers a range of topics including the fundamental workings of ECMs, basic electrical and electronic principles, and the identification and troubleshooting of common ECM issues. Students learn how to effectively diagnose problems using specialized diagnostic tools and software, and gain hands-on experience in repairing or replacing damaged ECM components. By the end of the course, participants are well-prepared to repair ECMs, making trucks run smoothly and reliably.
Truck ECM Course Topics
- How to open ECM and basic knowledge of ECM
- Introduce Multi meter
- How to Measure AC/DC Voltage?
- How to Measure Current?
- How to Measure Resistance?
- How to use continuity mode in multi meter?
- Introduce basic Electronics
- Series/parallel
- Functions and Workings of Series/Parallel Circuits
- AC/DC Current
- Understanding AC/DC Current
- AC/DC Voltage
- Understanding AC/DC Voltage
- Resistance
- Role of Resistance in an electrical circuit
- Capacitance
- Importance of Capacitance
- Series/parallel
- Component Knowledge
- Resistor
- Introduction of Resistor and its Functions
- Capacitor (Polar/Non Polar)
- Introduction of Capacitors (Polar/NonPolar)
- Inductor
- Role of an inductor in an electrical circuit
- Diode (Single/Dual Diode)
- Applications and Functions of Diode
- Transistor
- Importance of Transistor
- MOSFET
- Introduction of MOSFET, its Application and Uses
- Dual MOSFET
- Understanding Dual MOSFET, its Application and Uses
- Regulator
- Functions and Workings of Regulator
- Crystal Oscillator
- Introduction and Application of Crystal Oscillator
- Resistor
- SMD Rework of small components
- Diode
- Process for reworking a diode on an SMD board
- Resistor
- How to rework a small SMD Resistor
- Non Polar
- How to rework a nonpolar capacitor
- Etc.
- Diode
- SMD Rework of medium components
- Faulty Transistor
- Rework of Faulty Transistor on SMD Board
- MOSFET
- Understanding of Rework of MOSFET
- Regulator
- How to rework a Regulator
- Removing and Reworking of Small ICs (EEPROM, Regulator ICs, Etc.)
- Replacing an SMD Capacitor
- Etc.
- Faulty Transistor
- SMD Rework of multi components
- Understanding Rework of 2 Side Legs ICs
- Understanding Rework of 3 Side Legs ICs
- Reworking Large ICs on an SMD Board
- Reworking an MCU
- Basic knowledge of ECM hardware offline tracking
- Introduction of Ignition Circuit, Its Workings and Functions
- Understanding Communication Protocol Circuit
- Can High
- Can Low
- K-Line
- 5V Reference Circuit
- Importance of 5V reference circuit in ECM Operations
- Sensors Line
- Rail Pressure
- Crankshaft Position Sensor
- Cam Shaft Position Sensor
- Accelerator Position Sensor 1 and 2
- Water in Fuel Sensor
- Oil Pressure Sensor
- Coolant Temperature Sensor, Etc.
- What are Actuator Lines?
- Fuel Pump
- Radiator Fan
- Fuel Pump Actuator
- Engine Indicator Lamp Circuit
- Injector Circuit
- AC Compressor Relay
- Main Relay, etc.
- 24V Circuit
- How to diagnose issues in 24V circuit
- Odometer Gauge signal from ecm Circuit
- Identification and analysis of common hardware related issues
- Techniques for repairing damaged or faulty circuit boards
- Basic knowledge of ECM hardware offline tracking
- How to Measure Onboard Voltages (Injector High Voltage, 5V, 3.3V, 2.5V, 1.5V, etc.)
- Explanation of hardware in different working section
- Explanation of ECM pinout and online tracking
- ECM data read and write
- K-Tag
- SM2 Pro
- BITBOX
- KT200
- PCM FLASH
- On table ECM testing
- On table ECM diagnosis
- Explanation of ECM calibration
- Explain JEMAT Tool & use of diagnostic software
Details of the Course
Fees – Rs. 85,000/- including GST
Hostel facility – 7,000/- per Month including food
Duration – 30 Days (Minimum)
Location – JustAuto Solutions Pvt. Ltd., Plot No: B1, B2, B3/15, Electronics Estate, GIDC, Sector 25, Gandhinagar, Gujarat
Hostel facility – 7,000/- per Month including food
Duration – 30 Days (Minimum)
Location – JustAuto Solutions Pvt. Ltd., Plot No: B1, B2, B3/15, Electronics Estate, GIDC, Sector 25, Gandhinagar, Gujarat
Certification and Recognition
